MAIN NTA
Cov khoom siv tau: Ntau hom kev lag luam muag muag thiab lwm hom kev lag luam sib xyaw.
Muaj feem xyuam: ntau yam yeeb yaj kiab, aluminium plating films, aluminium foil, ntawv, thiab lwm yam.
Kev tswj nruj hom: ntab yob, hloov pauv me me sensor.
Txheej chav tswj: servo motor
Main Technical Parameter
|
Qauv |
BD-1050B |
BD-1250B |
|
Max. ceev |
500m / min |
500m / min |
|
pub dav dav |
400-1050 hli |
500-1250 hli |
|
Max.rewind txoj kab uas hla |
Ø 800 mm |
Ø 800 mm |
|
Max.rewind txoj kab uas hla |
Ø 800 mm |
Ø 800 mm |
|
Paper core ntawm unwinding |
3 '' lossis 6 '' |
3 '' lossis 6 '' |
|
Daim ntawv tseem ceeb ntawm rewinding |
3 '' lossis 6 '' |
3 '' lossis 6 '' |
|
Ntug tidiness rau lamination |
± 2 hli |
± 2 hli |
|
Tag nrho lub zog |
cav 60kw |
cav 65kw |
|
Tshuab dimension |
5600 (l) * 2600 (w) * 2450 (h) hli |
5600 (l) * 2800 (w) * 2450 (h) hli |
|
Tshuab hnyav |
Kwv yees li 8500 kg |
Kwv yees li ntawm 9000 kg |
Optional Function
1.linear qhov rais, zoo li lub qhov rais
2.Composite dub thiab dawb zaj duab xis
Cov khoom siv tshwj xeeb
1. SMI-40 Ob lub ntsiab lus sib xyaw ua kua nplaum SMI-40
2. Ib qho kua nplaum nplaum feeder
3. Corona tshuab
4. Pab tshem tawm ncej
|
Laminating substrate |
Thickness ntawm substrate |
Txheej substrate |
Thickness ntawm substrate |
|
BOPP |
12-80μm |
BOPP |
12-80μm |
|
PETP |
8-30μm |
PETP |
10-30μm |
|
LDPE, LPE |
20-200μm |
LDPE, LPE |
30-200μm |
|
OPA |
12-18μm |
OPA |
12-18μm |
|
NYLON UAS |
20-80μm |
NYLON UAS |
30-80μm |
|
ALU (Foil) |
6.3-40μm |
PP CAS TSIS TAU |
60-150μm |
|
PP CAS TSIS TAU |
20-150μm |
Daim ntawv |
40-150gsm ua |
|
COV FILM |
20-200μm |
|
|
Taw qhia:
Lub hnab ntim dej khov uas tsis muaj kuab tshuaj laminating tshuab yog lub tshuab txiav-ntug uas hloov tag nrho cov txheej txheem lamination ntawm cov hnab khov. Lub tshuab tshiab no lub hom phiaj los muab cov txheej txheem txhim khu kev qha, hnyav-dawb lamination los tsim cov khoom khov nab kuab zoo thiab ruaj khov.
Ib qho ntawm qhov zoo ntawm lub tshuab no yog nws tus phooj ywg ib puag ncig tsim. Lub laminated ice packs uas tsim los ntawm lub tshuab no muaj kev nyab xeeb rau kev siv nyob rau hauv ib puag ncig thiab ib puag ncig cov zaub mov tsis tas siv cov kuab tshuaj. Tsis tas li ntawd, kev tsim cov kuab tshuaj tsis muaj zog ntawm lub tshuab txo cov nqi cuam tshuam nrog kev yuav khoom, kev ua, thiab pov tseg cov kuab tshuaj.
Lwm qhov zoo dua ntawm cov kuab tshuaj tsis muaj kuab tshuaj laminating tshuab yog lawv cov txiaj ntsig. Lub tshuab no tau nruab nrog cov thev naus laus zis siab heev thiab cov txheej txheem ua kom zoo kom ntseeg tau tias lamination ceev thiab raug, yog li ua tiav cov khoom tsim tau zoo. Qhov no txhais tau hais tias cov tuam txhab muaj peev xwm tsim tau ntau laminated ice packs nyob rau hauv lub sij hawm luv luv, txhim kho kev ua hauj lwm efficiency thiab txo nqi.
Ntxiv nrog rau kev ua tus phooj ywg ib puag ncig thiab ua haujlwm tau zoo, kev ua haujlwm ntawm lub hnab ntim dej khov tsis muaj kuab tshuaj laminating tshuab kuj yooj yim heev. Nws cov neeg siv-phooj ywg tsim ua kom ntseeg tau tias txawm tias cov neeg pib tshiab tuaj yeem kawm sai sai ua haujlwm ntawm lub tshuab nrog kev saib xyuas tsawg, ua kom yooj yim rau cov txheej txheem.
Zuag qhia tag nrho, lub hnab ntim dej khov tsis muaj kuab tshuaj laminating tshuab yog qhov hloov pauv kev ua si hauv lub hnab ntim dej khov kev lag luam. Nws tus phooj ywg zoo ib puag ncig, siv tau zoo, thiab tus neeg siv tus qauv tsim pab cov lag luam txhim kho cov khoom tsim tau, txo cov nqi, thiab tsim cov khoom zoo laminated ice packs.
